Posted on

ALTERA USB Blaster ByteBlaster II CPLD FPGA Download Cable JTAG Chain Debugger


Feature:
1.Stably support SignalTap II embedded logic analyzer function ,no mistake while crawlling data;
2. Fully support all Altera products such as :
CPLD: MAX3000, MAX7000, MAX9000 and MAXII
FPGA: Stratix, StratixII, StratxIII, Cyclone, CycloneII, CycloneIII, ACEX1K, APEX20K and FLEX10K etc.
Active serial configuration device: EPCS1, EPCS4, EPCS16, EPCS64 etc.
Enhanced configuration devices: EPC1, EPC4.
3. Supports 3 download mode: AS, PS and JTAG;
4. Support and Nios II embedded soft core processor communication and debugging, Rev.C latest version Hardware. Support jtag_uart;
5. Speed??: 6 times faster than parallel port download cable ByteBlasterII;
6. Easy to use: MiniUSB interface, easy connection, two status indicator makes debugging more comfortable.
7. Fully compatible with ALTERA USB Blaster, functionality and performance are the same as ALTERA original download cable.
8: Voltage : 1.5~5V JTAG IO Voltage .
System configuration:
1, Windows XP, Windows Vista, Windows7 , USB interface;
2, Quartus II version 4.0 or newer version;
Package Content:
1x Altera USB Blaster;
1x 10-Pin Flex Cable;
1x USB wire

Posted on

DR.Fix 6in1 eMMC Adapter for EASY JTAG/EASY JTAG Plug/UFI/RIFF/RIFF2/Medusa/GPG/ORT eMMC Box Programmer Read BGA153/162/221/529 Memory FBGA Programming-ALLSOCKET


ALLSOCKET DR.Fix Kit-6in1 eMMC Repair Adapter Tool for Universal eMMC Boxes Programmer to Read and Write eMMC153/169, eMCP221,eMCP162/186, eMCP529 Flash Memory
We are original manufacturer, and look for distributor / dealer, contact us for more info if you’re interested(Email: amanda(@)allsocket.com)

Product Feature:
*One box one connector for all chip sizes
*No more connector board problems, stable, efficient and easy to operate
*No need to solder wires to eMMC Chip
*No more VCC problem
*compatible with most mainstream eMMC read / write programmer tools
*supports eMMC/eMCP packages: eMMC153/169, eMCP221,eMCP162/186, eMCP529 *Time saver: easy to operate and disassemble

Compatible with professional eMMC Box:
a. Z3X Easy-JTAG
b. Medusa Pro
c. UFI Box
d. ATF Box
e. Riff Box(Riff 1, Riff 2)
f. eMMC Pro, eMMC Booster
g. GPG EMMC
h. other common interface boxes

Package contained:
1*DR.Fix Kit-6in1 eMMC Repair Adapter
1* Set of Size Limiter/Frame(11*10, 11.5*13, 12*16, 12*18, 14*18, 15*15mm)
1* SD Convertor Adapter
1* RegisteredJack Cable
1* ISP Adapter

Posted on

Black Flash USB+ Universal Memory Programmer with Integrated USB to COM(TTL) and Two Port USB 2.0 Hub


Compatible with FlashcatUSB, this device can program all CFI compatible flash devices over JTAG and can also program SPI high-density serial flash devices.

Hardware support can be added using a easy to use device script feature.

Features:

  1. Universal CFI Flash programming support
  2. 2 DIP switches for mode application changes
  3. Upgradeable firmware over USB
  4. On board reset button
  5. SPI Mode 0, 1, 2 compatible
  6. Dual voltage (3.3v or 5v) output
  7. USB to Serial (TTL) converter
  8. USB 2.0 Hub (Two Ports)

Includes:

  1. Black Flash USB+ Universal Memory Programmer
  2. 80 Pin dual row IDC header (2.54mm spacing)
  3. 8 PCS female to female jumper wire (20 cm)

Open source software supports Windows 2000, 2003, XP, Vista and Win7 (32-bit and 64-bit versions)

Posted on

Seeedstudio XC2C64A CoolRunner-II CPLD development board


Ever get stuck choosing the right logic chip combination or voltage level translator? Give up the hunt and create your own custom logic chip. CPLDs can give you the logic you need, with the pinout you want, while saving board space and board revisions.

The CoolRunner-II XC2C CPLD has two separate banks of pins that can operate at different voltages, internal pull-up resistors, and pin keepers. This development board from Dangerous Prototypes will help you build your first custom logic chip using simple schematic entry, Verilog, or VHDL.

XC2C64A CPLD with 64 macrocells
On-board 1.8volt supply for the core
On-board 3.3volt supply for pins
Separate pin banks can be operated at different voltages (1.2volt to 3.3volt)
Selectable 1.8volt, 3.3volt, and external supply for each pin bank
LEDs for output
Push button for input
Populated JTAG header
Easy to program with the Bus Pirate and Bus Blaster (Not Included)
Open source (CC-BY-SA)

Posted on

eMMC Pro Box New Universal High-Speed EMMC Device Programmer Designed for Low-level Operations


Hardware Features
In-System Programming as known as ISP
It is the ability of devices to being programmed while installed in a complete system , rather than requiring the chip to be programmed prior installing or prior to being mounted .ISP operations enables users to directly recover the complete data without removing the chip ( eMMC , eMCP, NAND ,etc.. )
Integrated Voltage Control
All (I/O) levels will be detected automatically for the eMMC / Device Levels
eMMC Pinout / Connections
D0 / DAT0 / DATA0 , CMD , CLK , VCC , VCCQ , GND
The more D/DAT/DATA pin connected the faster it will be .
Most eMMC devices are 8bit(s) ( D0,D1,D2,D3,D4,D5,D6,D7)
Support Page
Free Unlimited Technical Documents , Pinouts , Manuals Free Unlimited Mobile phone Dumps , Files resources
Low-Level Access

eMMC Pro HW and SW is able to acces the eMMC every part / partitions and zones so you won’t miss a spot ! eMMC Pro is designed for Low-Level Operations and designed for Professionals not just a Simple Reader

eMMC PRO

Software Features

USER Area access Read / Write / Erase / Format
BOOT 1 Access Read / Write
BOOT 2 Access Read / Write
extCSD Access Read / Write
*GPP1 Access Read / Write
*GPP2 Access Read / Write
*GPP3 Access Read / Write
*GPP4 Access Read / Write
*RPBM Read / Write

Package Contains:
eMMC PRO Box – 1 pc.
eMMC Booster Box – 1 pc. eMMC IC Adapter (breakout PCB) – 2pcs. 20-pin flat cable – 2 pcs. Soldering cables – 1 set Roll wire – 1pc.

Posted on

Octoplus Box JTAG with JIGs Set


Octoplus Box JTAG old version – the most robust and frequently updated tool for Samsung, LG and other brands on the market!

Octoplus Box is a groundbreaking phone servicing solution that combines unibox and JTAG interfaces and supports over 530 Samsung, 900 LG and 460 by JTAG mobile devices.

Octoplus Box JTAG – Outstanding Features:

  • Repair IMEI
  • Unlock
  • Read Boot/Flash
  • Write Boot/Flash
  • Erase Boot/Flash
  • Repair Boot/Flash
  • Multilingual software interface

    Please note that you can perform a wide range of servicing operations with Octopus/Octoplus Server Credits, Octopus/Octoplus Unlimited Sony Ericsson Activation, Octopus/Octoplus Samsung Activation and Octopus/Octoplus LG Activation.
    Octoplus Box Hardware
    FTDI integrated circuit for COM-port emulation via RJ45 socket for servicing mobile phones
    Innovative Alcor smart-card controller for rock solid smart-card protection
    Industrial grade fast 55 MHz ARM7 32-bit RISC processor for JTAG operations via RJ50 socket
    RJ50 male to 20-pin female adapter available for easy and convenient 3rd party JIGs usage

    Purchasing Octoplus Box JTAG You Get
    Octoplus Box
    Integrated JTAG interface
    6 months of warranty
    6 months of FREE access to the premium flash file download area at Boot-Loader v2.0
    Free Octoplus Box Support Area
    JTAG set JTAG Clip by GsmServer – 1pc.
    Set of large diameter needles (P75-B) – 25 pcs.
    Set of small diameter needles (P50-B) – 25 pcs.
    Set of JIG adapters – 6 pcs.
    Set of RJ-50 (10P10C) cables for soldering – 5 pcs.
    Octoplus JIG adapter – 1pc.
    Copper wire 0.1 mm – 1pc.

    Posted on

    Octoplus Box Samsung + LG + JTAG Activated with Optimus Cable Set + JIG Set


    Octoplus Box old version – the most robust and frequently updated tool for Samsung, LG and other brands on the market!

    Octoplus Box is a groundbreaking phone servicing solution that combines unibox and JTAG interfaces and supports over 530 Samsung, 900 LG and 460 by JTAG mobile devices.

    Octoplus Box – Outstanding Features:
    Direct decode
    All locks reset
    Firmware update
    Read/write Full Flash and Calibration data files
    Read firmware version
    Full factory reset
    LG 3G-Cyon-Show-FOMA phones support
    Anycall phones support
    Repair IMEI
    Read Boot/firmware
    Write Boot/firmware
    Erase Boot/firmware
    Restore Boot/firmware
    Multilingual software interface

    Octoplus Box Hardware
    FTDI integrated circuit for COM-port emulation via RJ45 socket for servicing mobile phones
    Innovative Alcor smart-card controller for rock solid smart-card protection
    Industrial grade fast 55 MHz ARM7 32-bit RISC processor for JTAG operations via RJ50 socket
    RJ50 male to 20-pin female adapter available for easy and convenient 3rd party JIGs usage

    Package Contains:
    Octoplus Box
    Integrated JTAG interface
    6 months of warranty
    6 months (with 50 GB download limit) of FREE access to download area at Boot-Loader v2.0
    Free Octoplus Box Support Area
    Set of cables and JIGs Optimus cable set
    JTAG set JTAG Clip by GsmServer – 1pc.
    Set of large diameter needles (P75-B) – 25 pcs.
    Set of small diameter needles (P50-B) – 25 pcs.
    Set of JIG adapters – 6 pcs.
    Set of RJ-50 (10P10C) cables for soldering – 5 pcs.
    Octoplus JIG adapter – 1pc.
    Copper wire 0.1 mm – 1pc.

    Posted on

    Flashcat USB Memory Programmer BIOS MSI EEPROM NAND SPI JTAG I2C SERIAL (includes software + 3 cables)


    The most popular SPI, I2C and JTAG programming device in use today. Compatible with thousands of Flash memory devices. Connects directly via SPI, I2C or JTAG hardware headers. Specific hardware support can be added using a easy to use device script feature. Current support and compatibility SPI MODE (AVR 3.06) SPI mode 0, 1, 2 compatible I2C MODE (AVR 4.02) Supports all I2C and TWI devices All 24Cxx series supported. Address selectable (A0, A1, A2) Supports up to 400kHz data rates SPI EEPROM devices Supports 8-bit and 9-bit addressing JTAG MODE (AVR 7.05) CFI compatible memory Intel, AMD, and SST programming modes supported DRAM compatible memory Real-time reading and writing supported SPI compatible memory Broadcom and Atheros chipsets DMA Mode 100KB/S read and up to 50KBs write PrAcc Mode (non-dma) Full support for high (yet slow) compatibility MIPS Support (EJTAG) Version 1.x, 2.0, 2.5, 2.6 and 3.1 supported XILINX or CPLD devices Supports both SVF and XSVF file formats NAND MODE (AVR 1.07) 16 Mbit NAND over SPI bus such as Hynix HY27US08281A 256 Mbit NAND over SPI bus 512 Mbit NAND over SPI bus Such as SAMSUNG K9F4G08U0B Verified to work with these SPI Flash devices: Atmel, Spansion, Micron, Fidelix, Winbond, MXIC, EON, AMIC, Microchip (SST), PCT, PMC , Others Verified to work with these CFI Flash devices: Microchip (SST39), Intel (28F), MXIC, Toshiba, STMicroelectronics, Samsung , Fujitsu, Spansion, Hynix, Atmel (AT49), Sharp, Micron Works with SPI EEPROMS: Atmel AT25128B, AT25256B, AT25512; ST M95010, M95020, M95040, M95080, M95160, M95320, M95640, M95128, M95256, M95512, M95M01, M95M02 Verified MCU specific devices supported: Nordic nRF24LE1 (16KB flash over SPI), Xilinx CoolRunner-II series (XC2C32A, XC2C64A, XC2C128, XC2C256, XC2C384, XC2C512), Xilinx XC9500XL series (XC9500XL, XC95288XL, XC95144XL, XC9572XL, XC9536XL) Altera EPCS devices (EPCS1, EPCS4, EPCS16, EPCS64, EPCS128)

    Posted on

    Octoplus Box Full Set (LG and SAM Activated)


    Octoplus Box old version – the most robust and frequently updated tool for Samsung, LG and other brands on the market!

    Octoplus Box is a groundbreaking phone servicing solution that combines unibox and JTAG interfaces and supports over 530 Samsung, 900 LG and 460 by JTAG mobile devices.

    Octoplus Box – Outstanding Features:
    Direct decode
    All locks reset
    Firmware update
    Read/write Full Flash and Calibration data files
    Read firmware version
    Full factory reset
    LG 3G-Cyon-Show-FOMA phones support
    Anycall phones support
    Repair IMEI
    Read Boot/firmware
    Write Boot/firmware
    Erase Boot/firmware
    Restore Boot/firmware
    Multilingual software interface

    Octoplus Box Hardware
    FTDI integrated circuit for COM-port emulation via RJ45 socket for servicing mobile phones
    Innovative Alcor smart-card controller for rock solid smart-card protection
    Industrial grade fast 55 MHz ARM7 32-bit RISC processor for JTAG operations via RJ50 socket
    RJ50 male to 20-pin female adapter available for easy and convenient 3rd party JIGs usage

    Purchasing Octoplus Box You Get
    Octoplus Box
    Integrated JTAG interface
    6 months of warranty
    6 months of FREE access to the premium flash file download area at Boot-Loader v2.0
    Free Octoplus Box Support Area
    Set of cables and JIGs Optimus cable set
    JTAG set JTAG Clip by GsmServer – 1pc.
    Set of large diameter needles (P75-B) – 25 pcs.
    Set of small diameter needles (P50-B) – 25 pcs.
    Set of JIG adapters – 6 pcs.
    Set of RJ-50 (10P10C) cables for soldering – 5 pcs.
    Octoplus JIG adapter – 1pc.
    Copper wire 0.1 mm – 1pc.

    Posted on

    Z3X Easy-Jtag Plus Full Set for Phone Boot Repair, Data Recovery, and SPI Memory Programming


    Z3X Easy-Jtag Plus is an innovative all in one service tool for phone and phone boot repair, data recovery, SPI memory programming and many other features. Supports eMMC, ISP, JTAG, SPI, NAND and many more protocols.

    Hardware features:
    Updated Host MCU SAM3X8E
    Updated high-speed FPGA SPARTAN6
    Updated power management subsystem – full digital PWM with ADC control
    Added Micro-USB connector
    Added VCC and VCCQ switch with overcurrent protection
    Updated USB device interface: USB 2.0 480 Mbps
    Integrated ISP engine: Z3X high power pro engine (4 MB/s)
    Added eMMC 8-bit high-speed interface up to 42 MHz
    Integrated NAND* engine: NFC with 4 KB RAM buffer and ECC
    Integrated M-PHY* interface
    Integrated SPI engine: up to 21 MHz clock for popular SPI memory flash IC
    Integrated self-test core that excludes 90% faults in production

    Hardware benefits:
    Box to Host PC speed increased up to 40 MB/sec
    Compatible with old Easy JTAG 1st generation ISP adapters (1 bit)
    Compatible with most of the popular eMMC sockets (with supplied adapters)

    eMMC Socket – Features:
    Over 10K cycles of lifetime performance
    Support for a wide range of eMMC ICs
    High-speed up to 40 MB/sec through 8-bit bus
    EMI resistant design, low noise components
    Integrated power logic
    Surge protection – smart fuse driven (0.5A threshold)

    Z3X Easy-Jtag Plus Full Set – Package Content:
    Easy-JTAG Plus Box Hardware
    Z3X preactivated card with EasyJTAG PLUS Activation
    Z3X EMMC socket (BGA153/169, BGA162/186, BGA221, BGA529)
    USB A-B cable
    Adapter set (JTAG, ISP 1BIT, ISP 4BIT, U-SOCKET, E-SOCKET)
    1 year guaranteed free support access
    * The supplier retains the right to change some positions in the list of cables and accessories coming together with the product.

    Posted on

    Z3X Easy-Jtag Plus Lite Upgrade Set for Z3X Easy-Jtag Owners


    Z3X Easy-Jtag Plus Lite Upgrade Set is designated for those users, who already own Z3X Easy-Jtag, but want to increase its possibilities and enjoy new features.
    Z3X Easy-Jtag Plus is an innovative all in one service tool for phone and phone boot repair, data recovery, SPI memory programming and many other features. Supports eMMC, ISP, JTAG, SPI, NAND & other protocols.
    Offer is valid for the boxes activated before 07.07.2017.

    Hardware features:
    Updated Host MCU SAM3X8E
    Updated high-speed FPGA SPARTAN6
    Updated power management subsystem – full digital PWM with ADC control
    Added Micro-USB connector
    Added VCC and VCCQ switch with overcurrent protection
    Updated USB device interface: USB 2.0 480 Mbps
    Integrated ISP engine: Z3X high power pro engine (4 MB/s)
    Added eMMC 8-bit high-speed interface up to 42 MHz
    Integrated NAND* engine: NFC with 4 KB RAM buffer and ECC
    Integrated M-PHY* interface
    Integrated SPI engine: up to 21 MHz clock for popular SPI memory flash IC
    Integrated self-test core that excludes 90% faults in production

    Hardware benefits:
    Box to Host PC speed increased up to 40 MB/sec
    Compatible with old Easy JTAG 1st generation ISP adapters (1 bit)
    Compatible with most of the popular eMMC sockets (with supplied adapters)

    Z3X Easy-Jtag Plus Full Set – Package Content:
    Easy-JTAG Plus Box Hardware
    Free activation for new users (6 months old boxes)*
    USB A-B cable
    Adapter set (JTAG, ISP 1BIT, ISP 4BIT, U-SOCKET, E-SOCKET)
    1 year guaranteed free support access
    *A smart card is not included. Need to use the card from an old box.
    **The supplier retains the right to change some positions in the list of cables and accessories coming together with the product.

    Posted on

    Z3X Easy-Jtag+ Full Upgrade Set for Easy-Jtag Owners. Specially for Boxes activated after 2017.07


    Z3X Easy-Jtag Plus Full Upgrade Set is designated for those users, who already own Z3X Easy-Jtag, but want to increase its possibilities and enjoy new features.
    Z3X Easy-Jtag Plus is an innovative all in one service tool for phone and phone boot repair, data recovery, SPI memory programming and many other features. Supports eMMC, ISP, JTAG, SPI, NAND & other protocols.
    Offer is valid for the boxes activated after 07.07.2017.
    Hardware features:
    Updated Host MCU SAM3X8E
    Updated high-speed FPGA SPARTAN6
    Updated power management subsystem – full digital PWM with ADC control
    Added Micro-USB connector
    Added VCC and VCCQ switch with overcurrent protection
    Updated USB device interface: USB 2.0 480 Mbps
    Added eMMC 8-bit high-speed interface up to 42 MHz
    Integrated NAND* engine: NFC with 4 KB RAM buffer and ECC
    Integrated SPI engine: up to 21 MHz clock for popular SPI memory flash IC

    Hardware benefits:
    Box to Host PC speed increased up to 40 MB/sec
    Compatible with most of the popular eMMC sockets (with supplied adapters)

    eMMC Socket – Features:
    Support for a wide range of eMMC ICs
    High-speed up to 40 MB/sec through 8-bit bus
    EMI resistant design, low noise components
    Integrated power logic
    Z3X Easy-Jtag Plus Full Upgrade Set – Package Content:
    Z3X EMMC socket (BGA153/169, BGA162/186, BGA221, BGA529)
    Easy-JTAG Plus Box hardware
    Free activation for new users (boxes that have been in use for less than 6 months)
    USB A-B cable
    Adapter set – 5 pcs. (JTAG, ISP 1BIT, ISP 4BIT, U-SOCKET, E-SOCKET)
    1 year free support
    *Smart card is not included. Need to use the card from an old box.
    * The supplier retains the right to change some positions in the list of cables and accessories coming together with the product.

    Posted on

    Z3X Easy-Jtag Plus Full Upgrade Set for Z3X Easy-Jtag Owners


    Z3X Easy-Jtag Plus Full Upgrade Set is designated for those users, who already own Z3X Easy-Jtag, but want to increase its possibilities and enjoy new features.
    Z3X Easy-Jtag Plus is an innovative all in one service tool for phone and phone boot repair, data recovery, SPI memory programming and many other features. Supports eMMC, ISP, JTAG, SPI, NAND & other protocols.
    Offer is valid for the boxes activated before 07.07.2017.
    Hardware features:
    Updated Host MCU SAM3X8E
    Updated high-speed FPGA SPARTAN6
    Updated power management subsystem – full digital PWM with ADC control
    Added Micro-USB connector
    Added VCC and VCCQ switch with overcurrent protection
    Updated USB device interface: USB 2.0 480 Mbps
    Added eMMC 8-bit high-speed interface up to 42 MHz
    Integrated NAND* engine: NFC with 4 KB RAM buffer and ECC
    Integrated SPI engine: up to 21 MHz clock for popular SPI memory flash IC

    Hardware benefits:
    Box to Host PC speed increased up to 40 MB/sec
    Compatible with old Easy JTAG 1st generation ISP adapters (1 bit)
    Compatible with most of the popular eMMC sockets (with supplied adapters)

    eMMC Socket – Features:
    Support for a wide range of eMMC ICs
    High-speed up to 40 MB/sec through 8-bit bus
    EMI resistant design, low noise components
    Integrated power logic
    Z3X Easy-Jtag Plus Full Upgrade Set – Package Content:
    Z3X EMMC socket (BGA153/169, BGA162/186, BGA221, BGA529)
    Easy-JTAG Plus Box hardware
    Free activation for new users (6 months old boxes)
    USB A-B cable
    Adapter set – 5 pcs. (JTAG, ISP 1BIT, ISP 4BIT, U-SOCKET, E-SOCKET)
    1 year guaranteed free support access
    *Smart card is not included. Need to use the card from an old box.
    * The supplier retains the right to change some positions in the list of cables and accessories coming together with the product.

    Posted on

    Z3X Easy-Jtag Plus Lite Set for Phone Boot Repair, Data Recovery, and SPI Memory Programming


    Z3X Easy-Jtag Plus is an innovative all in one service tool for phone and phone boot repair, data recovery, SPI memory programming and many other features. Supports eMMC, ISP, JTAG, SPI, NAND and many more protocols.

    Z3X Easy-Jtag Plus – Hardware features:
    Updated Host MCU SAM3X8E (comparing to LPC1768 in old box)
    Updated high-speed FPGA SPARTAN6 (comparing to SPARTAN3 in old box)
    Updated power management subsystem – full digital PWM with ADC control
    Added Micro-USB connector (if additional power required)
    Added VCC and VCCQ switch with overcurrent protection
    Updated USB device interface: USB 2.0 480 Mbps (high speed)
    Integrated ISP engine: Z3X high power pro engine (4 MB/s)
    ISP support 1 and 4 bit* connection
    Added eMMC 8-bit high-speed interface up to 42 MHz
    Integrated NAND* engine: NFC with 4 KB RAM buffer and ECC
    Integrated M-PHY* interface
    Integrated SPI engine: up to 21 MHz clock for popular SPI memory flash IC
    Integrated self-test core that excludes 90% faults in production
    Integrated CCID card reader for Z3X Software Use

    Z3X Easy-Jtag Plus – Hardware benefits:
    Box to Host PC speed increased up to 40 MB/sec
    JTAG Interface speed increased by 20%
    Compatible with old Easy JTAG 1st generation ISP adapters (1 bit)
    Compatible with most of the popular eMMC sockets (with supplied adapters)
    Full support for Windows XP
    Z3X Easy-Jtag Plus Lite Set – Package Content:
    Easy-JTAG Plus Box Hardware
    Z3X preactivated card with EasyJTAG PLUS Activation
    USB A-B cable
    Adapter set (JTAG, ISP 1BIT, ISP 4BIT, U-SOCKET, E-SOCKET)
    1 year guaranteed free support access

    * The supplier retains the right to change some positions in the list of cables and accessories coming together with the product.

    Posted on

    Z3X Easy-Jtag+ Lite Upgrade Set for Easy-Jtag Owners. Specially for Boxes activated after 2017.07


    Z3X Easy-Jtag Plus Lite Upgrade Set is designated for those users, who already own Z3X Easy-Jtag, but want to increase its possibilities and enjoy new features.
    Z3X Easy-Jtag Plus is an innovative all in one service tool for phone and phone boot repair, data recovery, SPI memory programming and many other features. Supports eMMC, ISP, JTAG, SPI, NAND and much more protocols.
    This Special Offer is valid for the boxes activated only after 07.07.2017.

    Z3X Easy-Jtag Plus – Hardware features:
    Updated Host MCU SAM3X8E
    Updated high-speed FPGA SPARTAN6
    Updated power management subsystem – full digital PWM with ADC control
    Added VCC and VCCQ switch with overcurrent protection
    Updated USB device interface: USB 2.0 480 Mbps (high speed)
    Integrated ISP engine: Z3X high power pro engine (4 MB/s)
    Added eMMC 8-bit high-speed interface up to 42 MHz
    Integrated SPI engine: up to 21 MHz clock for popular SPI memory flash IC
    Integrated self-test core that excludes 90% faults in production

    Z3X Easy-Jtag Plus – Hardware benefits:
    Box to Host PC speed increased up to 40 MB/sec
    eMMC 1 Bit ISP Speed increased up to 4 MB/sec
    eMMC 4 Bit ISP Speed increased up to 12 MB/sec (eMMC 5.0+) **
    eMMC 4 Bit Speed up to 18 MB/sec
    eMMC 8 Bit Speed up to 28 MB/sec (eMMC 5.0+)
    Plug and Play for Windows OS 8/ 8.1/10

    Z3X Easy-Jtag Plus Lite Upgrade Set – Package Content:
    Easy-JTAG Plus Box Hardware
    Free activation for new users (boxes that have been in use for less than 6 months) *
    USB A-B cable
    Adapter set – 5 pcs. (JTAG, ISP 1BIT, ISP 4BIT, U-SOCKET, E-SOCKET)
    1 year guaranteed free support access
    *A smart card is not included. Need to use the card from an old box.
    * The supplier retains the right to change some positions in the list of cables and accessories coming together with the product.
